Hardware Design

Hardware Design

From simple 8-bit micro controller to leading-edge processor technology like ARM, ARC, FPGAs, DSPs, Skanda Systems hardware design solutions are in place at some of the world’s foremost companies.

No matter the demands of your project, our expertise with today’s latest sensor, communications, display, power management, and imaging technologies assure you a complete, effective solution.

Skanda Systems engineers can advise you on, and implement the solutions that best meet your specific requirements.

Our experience spans the full spectrum of industry-leading design tools, including Altium, Cadence, and Mentor.

We design the board to the Design Specification, employing techniques to meet with client type approvals such as EMC emissions, temperature range, vibration, and circuit protection.

Completed schematics are then sent for approval before moving to the board layout stage.

Our Design Engineers then proceed to the board layout stage considering specific physical parameters as highlighted within the Design Specification document.

We provide a 3D CAD model, or interactive 3D PDF, of the board to help clients visualise the final board layout.

We test the boards and revise if necessary.

We deliver full documentation with Gerber files as part of the delivery items of the project.

PCB Design & Development

Our services range from simple single layer LED designs, to multi-layer, multi-processor behemoths.

Skanda Systems years of experience and vast prepared component library ensures our PCB design is undertaken efficiently and cost-effectively.

Investing in the very latest tools and predominantly utilising the Altium suite, we can ensure optimum manufacturability and yield from any PCB design we undertake.

We typically undertake PCB designs as a part of a project from inception to completion.

However, we also cater to the needs of customers offering individual elements of the process, helping their engineering team achieve fast time-to-market requirements.

Our unrivalled design engineers with a combination of skills and knowledge drawn from many years of practical industry experience are capable of delivering Hardware Solutions with industry compliance standards such as EMC, ATEX Intrinsically Safe, DO-254, and DO-278A, to name a few.

All our design engineers are fully trained to recognised IPC CID+ standards for circuit and PCB design.

This includes specific capabilities in:

• Design For eXcellence (DFX)
• Design for Manufacture (DFM)
• Design for Test (DFT)
• Design for Assembly (DFA)

Skanda Systems can work with you for entire product development with hardware design inclusive, or Schematic Design, PCB Design, and PCB Testing as individual elements.

We analyse and research for reliability and cost effectiveness to yield the perfect hardware solution required for your application needs.
